Green Solder Mask Quick Turn PCB Boards BGA Impedance Control 1.2mm 5mil

Place of Origin China
Brand Name Huashengxin
Certification UL , ISO9001
Model Number 112872
Minimum Order Quantity 1pcs
Packaging Details vacuum
Delivery Time fastest 24 hours for 2L and 4L prototype, 3 days for HDI board production
Payment Terms T/T

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
PCB Name 4 LAYER Quik Turn Fast PCB Marterial FR4 TG135
Surface Finished Immersion Gold Board Thickness 1.2mm
Copper Thickness 1/1/1/1OZ Min. Line Distance/space 5/5mil
Solder Mask Green Color KSM Smallest Mechanical Drilling Hole 0.25mm
Special Requirement Impedance Control/0.25mm BGA Applicationcommunications Products Industrial Control
High Light

1.2mm Quick Turn PCB Boards

,

5mil BGA Quick Turn PCB Boards

,

5mil BGA Circuit Board

Leave a Message
Product Description

Green Solder Mask Quick Turn PCB Boards BGA Impedance Control 1.2mm 5mil



Quick Turn PCB Boards Green Solder Mask Small BGA Impedance Control Fast Turn PCB PCB Fabrication



4 LAYER Quik turn Fast PCB



HSX products cover 1~32L FR-4 PCB, IMS PCB,HDI Boards, high frequency PTFE boards and Rigid-flex boards etc. It provides flexible quick turn production services (12 hours to72 hours), as well as small volume to big volume PCB manufacturing.Products are widely used in high-tech fields such as communications, power supplies, computer networks, digital products, industrial control, science and education, medical devices, and aerospace.



BGA Circuit Board Max layers: 32layer (≥20 layer needs to review)
Max finish panel size: 740* 500 MM(>600 MM needs to review)
Min finish panel size: 5 * 5mm
PCB material: PI +FR4,FR4, Rogers
PCB thickness: 0.2~4.0mm(<0.2 mm,>4 mm needs to review) (Board thickness ≤ 0.6mm,do not apply for HASL surface)
copper thickness of inner and outer base copper: Min 0.3/0.5oz,Max 3oz, advance 4-6oz
Bow and twist: 0.075%
Min. hole size: 0.15mm(<0.15 mm needs to review)
HDI Min drill hole: 0.08-0.10MM
PCB track/gap: 3mil(0.075mm)
PCB outline: Routing/V-CUT/Punching
Solder mask thickness: standard 15-20um; Advanced: 35um
Min solder mask bridge width: green 4mil,other colour 4.8mil
Solder mask filling holes: 0.1-0.5mm
The color of solder mask: green,matt green,blue,matt blue,black,matt black,yellow,red,white,etc
PCB silkscreen: White, Black and as your request
Peelable mask thickness: 500-1000um
Oxidation film of OSP: 0.2-0.5um



Layer counts: 4 layer Circuit board laminate: FR4
Different Copper thickness: 1/1/1/1OZ PCB Board thick: 1.6 MM
Smallest Mechanical drilling hole: 0.2 mm Min. line distance/space: 4/5mil
Solder mask color: Green color KSM Legends' color: White color
PCB surface finished: Immersion Gold Board profile: Milling+V-CUT
PCB Board Application: digital products
Requesting Special requirement: impedance control/0.25mm BGA



Green Solder Mask Quick Turn PCB Boards BGA Impedance Control 1.2mm 5mil 0

FAQ:
Q1: How can I get a quotation?
A: Please send us gerber file with format Gerber, PROTEL 99SE, PROTEL DXP, POWER PCB, CAM350, ODB and provide the demand quantities. We will provide quotation accordingly.



Q2: Can you manufacture the PCBs from a picture file?
A: No. But if you can send us a sample PCB, we could clone its design and work it out.



Q3: Do you have PCB in stock.
A: Most of the PCB boards are customized, and they have different designs, we produce them according to the gerber files provided by customers.



Q4: What FR4 materials do you usually use?

A: Kingboard, ITEQ, Shengyi...



Q5:What kind of shipment way do you usually use?
A: For small volume order, we always suggest to ship the boards by DHL,UPS,FedEx door to door service, we could use your shipping account to do collection or use our account to ship in DDU (import duty unpaid) delivery term.
And for big volume order, to save freight cost, we will suggest to arrange the shipment by air or by sea, Of course, if you have your own forwarder and can provide us the information, we can contact them to arrange the shipment.
