BGA Quick Turn PCB Boards FR4 Middle TG Immersion Gold Black Solder Mask

Place of Origin China
Brand Name Huashengxin
Certification UL , ISO9001
Model Number 135589
Minimum Order Quantity 1pcs
Packaging Details vacuum
Delivery Time fastest 24 hours for 2L and 4L prototype, 3 days for HDI board production
Payment Terms T/T

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
PCB Name BGA Quick Turn PCB Boards Marterial FR4, Middle TG
Board Thickness 1.6MM Copper Thickness 1/1/1/1oz
Smallest Mechanical Drilling Hole 0.2mm Min. Line Distance/space 4/4mil
Treatment Finished Immersion Gold Solder Mask Black
Special Requirement Impedance Control/0.25mm BGA/mid TG
High Light

Middle TG Quick Turn PCB Boards

,

1.6MM Quick Turn PCB Boards

,

BGA quick turn circuit boards

Leave a Message
Product Description

Black Solder Mask Quick Turn PCB Boards FR4 middle TG



4L Small BGA Quick Turn PCB

Copper thickness of inner and outer base copper capability: Min 0.3/0.5oz,Max 3oz, advance 4-6oz

Bow and twist tolerance: 0.075%

Min. hole size: 0.15mm(need to review the board if smaller than 0.15 mm )

HDI Min drill hole capability: 0.08-0.10MM
PCB track/gap capability: 3mil(0.075mm)
PCB outline method: Routing/V-CUT/Punching

Solder mask thickness capability: standard 15-20um; Advanced: 35um

Min solder mask bridge width capability: green 4mil,other colour 4.8mil

Solder mask filling holes capability: 0.1-0.5mm

The color of solder mask covers green, matt green, blue, matt blue, black, matt black, yellow, red, white, etc
PCB silkscreen includes white, Black and as your request



Features and benefits

1. High TG industrial standard material shows excellent thermal reliability;

2. Immersion gold ensure excellent wetting during component soldering and avoid copper corrosion;

3. In house, engineering design prevents problems from occurring in pre-production;

4. ISO9001, ISO14001, IATF16949, ISO13485, UL Certified;

5. Customer complaint rate: <1%

6. Delivery on time: >98%

7. Prototype PCB capability to Volume Production capability;

8. Multilayer and Any Layer HDI PCBs;

9. More than 18+ years of PCB experience.



PCB Layer 4L PCB material FR4 TG150
Copper thickness 1/1/1/1OZ PCB thickness 1.6MM
Min. hole size 0.20mm Min.PCB track/gap: 4/4mil
PCB solder mask Black PCB silkscreen White
PCB surface finished Immersion Gold PCB outline Routing
Application industrial control
Special requirement: impedance control/0.25mm BGA/mid TG
